Stainless Steel Two Piece Ball Valve with Mounting Pad

$42.00

Sale Sold out

Taxes included.

SKU:BV-3-MP-015

Size 15mm (½″) 20mm (¾″) 25mm (1″) 32mm (1¼″) 40mm (1½″) 50mm (2″) 65mm (2½″) 80mm (3″) 100mm (4″)

Size: ½" to 4"
Body: ASTM A351 - CF8M
Seat: PTFE
Pressure Rating: 1000 PSI (69 BAR) W.O.G
Thread / Ends: Pipe thread in accordance with BS 21:1973
End Options: SW / BSPP / NPT

This two-piece stainless steel ball valve combines robust flow control with the convenience of an ISO mounting pad for easy actuation. The full-bore design ensures unrestricted flow and minimal pressure drop, making it suitable for demanding industrial and commercial applications.

Its two-piece construction allows simple maintenance and cleaning, while BSP threaded ends provide secure and reliable pipeline integration. The precision-engineered stainless steel body, floating ball, and PTFE seats deliver smooth quarter-turn operation and a leak-tight seal. The ISO 5211 mounting pad enables direct installation of pneumatic or electric actuators, offering flexibility for both manual and automated systems. Durable stainless steel construction ensures excellent resistance to corrosion and long service life in water, air, oil, gas, and chemical applications.

SIZE	d1	L	H	W	S	h1	d2	d3	d4	R1	R2	Weight (kg)	Torque (Nm)
15	15	65	60	120	9	8.5	31	36	42	2.75	2.75	0.55	5.5
20	20	75	64	120	9	8.5	31	36	42	2.75	2.75	0.73	7.5
25	25	85	74	148	11	11	35.5	42	50	2.75	3.5	1.08	11
32	32	101	79	148	11	11	35.5	42	50	2.5	3.5	1.67	15
40	38	112	95	178	14	13.5	56	50	70	3.5	4.5	2.57	20
50	50	130	103	178	14	13.5	56	50	70	3.5	4.5	3.72	40
65	63	162	123	325	17	20.5	76	70	102	4.5	5.5	7.12	60
80	76	188	131.5	325	17	20.5	76	70	102	4.5	5.5	10.2	85
100	96	224	165.5	325	22	22.5	100	102	125	5.5	6.5	19.4	150

NO	PART NAME	MATERIAL
1	BOLT	AISI 304
2	BOLT NUT	AISI 304
3	SPRING WASHER	AISI 304
4	CAP	ASTM A351 CF8M
5	BODY	ASTM A351 CF8M
6	BALL	ASTM A351 CF8M
7	BALL SEAT	RTFE
8	BODY SEAL	PTFE
9	THRUST WASHER	PTFE
10	PACKING	PTFE
11	O-RING	VITON
12	STEM	ASTM A276-316
13	GLAND RING	AISI 304
14	BELLEVILLE WASHER	AISI 304
15	LOCK WASHER	AISI 304
16	LOCK DEVICE	AISI 304
17	STEM NUT	AISI 304
18	HANDLE	AISI 304
19	HANDLE SLEEVE	PVC
